In zinc alloy die casting, Zamak 2, Zamak 3, and Zamak 5 are commonly used zinc-aluminum alloys.
The main difference among these materials is their copper content, which affects strength, hardness, ductility, dimensional stability, and long-term aging performance.
In general, Zamak 3 is the most widely used and versatile zinc die casting alloy.
Zamak 5 contains approximately 1% copper, providing higher strength and hardness than Zamak 3.
Zamak 2 contains approximately 3% copper and offers the highest strength and hardness among the Zamak family.
But its long-term dimensional stability, ductility, and impact resistance should be carefully considered.
| Item | Zamak 2 | Zamak 3 | Zamak 5 |
|---|---|---|---|
| Common material names | ZP0430 / ZL0430 / AC43A | ZP0400 / ZL0400 / AG40A / ZDC2 | ZP0410 / ZL0410 / AC41A / ZDC1 |
| Main composition | Zn + Al + Mg + Cu | Zn + Al + Mg | Zn + Al + Mg + Cu |
| Copper content | Approx. 2.6–3.0% | Very low | Approx. 0.7–1.2% |
| Material positioning | High strength and high hardness | General-purpose and dimensionally stable | Higher strength and hardness than Zamak 3 |
| General usage frequency | Less common, for special applications | Most common | Common, especially in European applications |
